TAMIYA 45071 Tamiya Brushless Electronic Speed Controller 05SR (Sensored) NEW - call for discount pricing!

This ESC is designed only for use with Tamiya Brushless Motors (Sensored).

• Dedicated brushless motor connectors enable more efficient power supply.
• Motor connectors can be directly connected to motor.
• The FET (Field Effect Transistor) layout features parallelization to reinforce high current resistance.
• The maximum-RPM is the same level as the TBLE-04SR.
• The black-anodized aluminum case works as heat sink to ensure improved heat dissipation, and 25mm square cooling fan can be attached. (*The TBLE-04SR had plastic case.)
• Features a receiver switch with screw-attached switch case which protects cables and reinforces case rigidity.
• The TBLE-05SR has a set button on the switch for easier setup changes while the TBLE-04SR had it on the ESC.
• Settings such as battery cut-off, reverse, brake, soft start and neutral brake can be changed by the set button and can be checked by three LED lights and sounds.
• Features overheat and overload protection functions to help ensure that your equipment avoids damage.
• Compatible with Item 54612 Tamiya Brushless Motor 02 (Sensored) 15.5T.
• Includes 270mm sensor cable.
• Maximum continuous current: 90A
• Input voltage: 6.6V - 7.2V
• Weight: 76g (including cables)
• Dimensions (approximate): 42.5 x 33.5 x 24.5mm (with fan: 42.5 x 33.5 x 33.5 mm)
